SciMedia specializes in complete turn-key, optical mapping systems for neuroscience and cardiac research.

Optical Mapping System MiCAM Series
High-Speed Optical Mapping System
MiCAM03-N256

1,000 fps at 256x256 pixels
Original Large CMOS Image Sensor

High Speed Imaging System MiCAM03-N256
Bio Imaging
  • Voltage Sensitive Dye
  • Calcium Dye
  • GCaMP
  • GEVI
  • Intrinsic Optical Signal
  • and more...
Bio Imaging

Imaging Applications

Products for High-Speed Fluorescence Imaging

Multi-function, high-speed optical mapping system MiCAM05-N256

MiCAM05-N256

Multi-function, high-speed optical mapping system. Imaging speed of up to 1,923 fps with 256x256 pixels. Up to 4 cameras can be connected.

High-speed optical mapping system MiCAM03-N256

MiCAM03-N256

High-speed optical mapping system. Imaging speed of up to 1,000 fps with 256x256 pixels. Up to 2 cameras can be connected.

An Ultra-Sensitive Optical Mapping System MiCAM03-C35IR

MiCAM03-C35IR

An ultra-sensitive, wide-field optical mapping system equipped with a large 35mm full-size CMOS sensor with 2,160x1,280 pixels.

Fluorescence Mesoscope THT

THT Series

A mesoscope developed for fluorescence imaging such as voltage sensitive dye imaging, calcium imaging and GCaMP imaging.

LED Light Source LEX9

LEX9

An LED light source developed in pursuit of high brightness, high stability, and simple operability. Suitable for voltage sensitive dye imaging, calcium imaging and GCaMP imaging.

Analysis Software BV Workbench

BV Workbench

Software developed for analysis of optical mapping data such as neural activity and cardiac activity. Various image analysis can be performed quickly.

Multi-Device Synchronizer ESTM10

Multi-Device Synchronizer ESTM10

All-in-one system with functions including stimulus pulse output, acquisition timing control for camera, lighting control for LED light sources, biological signal recording, and digital oscilloscope, etc.

Our Advantages

custom-made CMOS sensor dedicated to high-speed imaging
Custom CMOS image sensors having high speeds, wide dynamic range, and low noise
Our cameras are used to detect both voltage sensitive dye signals and calcium signals at optimal S/N ratios.
MiCAM imaging system
Optical mapping system, optics, and software developed based on 25 years of experience
Turnkey systems are ready for immediate use. Custom-made products are also available upon customers requests.
reference papers
700 scientific research papers have been published using our optical mapping systems
Our systems are used by customers in over 220 universities, research institutes, and companies. 420 units have been installed in the last 25 years.

Other products

Cardiac Signal Acquisition System CIOS8

Cardiac Signal Acquisition System CIOS8

Activity of cardiomyocytes in a culture plate can be measured without invasion. Number of beats and contraction time are automatically detected
